175 / 212
173
Eyeline® Bespoke Screen Service
We offer a much wider range of screens that are made to order - contact us for further details.
Eyeline® Max
Projection Screens
Large format projection screens with black borders
to all 4 sides which enhance the projected image,
providing a professional presentation.
Channel fix mounting brackets for wall or ceiling.
Quiet motor during operation.
Matte white projection material.
Video 4:3, Widescreen 16:9 and 16:10 formats.
Additional black cloth to the top of all models for
optimal viewing height.
Supplied with bare end cable and wall switch.
Optional remote accessories - see page 176.
Channel fix mounting
Eyeline®Max Projection Screens
ScreenSize
A
Height
B
Width
ViewArea
C
Height
D
Width
Format
Max.Drop
E
CaseSize
F
Length
G
Height
H
Depth
Diagonal
I
Weight
Code
Price
2650mm 3500mm 2550mm 3400mm 4:3 2995mm 3600mm 145mm 147mm 167 inch 30kg
M350V
£1497.84
3020mm 4000mm 2920mm 3900mm 4:3 3365mm 4100mm 145mm 147mm 192 inch 33kg
M400V
£1686.56
3400mm 4500mm 3300mm 4400mm 4:3 3595mm* 4600mm 145mm 147mm 217 inch 36kg
M450V
£1997.07
2230mm 3500mm 2130mm 3400mm 16:10 2875mm 3600mm 145mm 147mm 158 inch 30kg
M350ST
£1497.84
2540mm 4000mm 2440mm 3900mm 16:10 3185mm 4100mm 145mm 147mm 181 inch 33kg
M400ST
£1686.56
2850mm 4500mm 2750mm 4400mm 16:10 3195mm** 4600mm 145mm 147mm 204 inch 36kg
M450ST
£1997.07
2010mm 3500mm 1910mm 3400mm 16:9 2655mm 3600mm 145mm 147mm 154 inch 30kg
M350W
£1497.84
2290mm 4000mm 2190mm 3900mm 16:9 2935mm 4100mm 145mm 147mm 176 inch 33kg
M400W
£1686.56
2570mm 4500mm 2470mm 4400mm 16:9 2915mm** 4600mm 145mm 147mm 199 inch 36kg
M450W
£1997.07
Accessories see page 176
Screens include 50mm black borders on all 4 sides.
Additional extended black drop: 4:3 models have 200mm, 16:9 and 16:10 have 500mm (except * 50mm **200mm)
B
F
E
C
D
I
A
G
H
Eyeline® Max Key Features
✓
Image-enhancing black borders
✓
Channel fix mounting for wall or ceiling
✓
Quiet motor
✓
Additional black cloth at the top
for optimal viewing height
✓
Remote accessories available
✓
Bare end cable and wall switch supplied
