170
Projection Screens -
Wall Mounted Electric
Eyeline® Rollfix
Heavy Duty
Electric Screens
Deluxe heavy duty range of projection screens with
a robust steel housing.
Channel mounting system enabling a fast and easy
install (channel length 500mm at each end).
Hard wearing heavy duty matte white screen fabric
for clear and crisp images.
All models have a 300mm extended black drop
which ensures optimum viewing.
40mm black borders to side and bottom.
Requires electrical installation.
Motor situated on the right hand side.
Supplied with wall switch.
For remote control options see page 176.
Eyeline® Rollfix Heavy Duty Electric Screens
ScreenSize
A
Height
B
Width
ViewArea
C
Height
D
Width
Format
Max.Drop
E
CaseSize
F
Length
G
Height
H
Depth
Diagonal
I
Weight
Code
Price
1370mm 1800mm 1290mm 1720mm 4:3 1484mm 1940mm 87mm 87mm 2150mm 12.7kg
RFV180*
£584.27
1520mm 2000mm 1440mm 1920mm 4:3 1634mm 2140mm 87mm 87mm 2400mm 14.1kg
RFV200*
£608.95
1820mm 2400mm 1740mm 2320mm 4:3 1934mm 2540mm 87mm 87mm 2900mm 17.1kg
RFV240*
£785.42
2270mm 3000mm 2190mm 2920mm 4:3 2402mm 3140mm 105mm 105mm 3650mm 25.3kg
RFV300*
£1125.93
1160mm 1800mm 1080mm 1720mm 16:10 1274mm 1940mm 87mm 87mm 2031mm 12.4kg
RFST180
£584.27
1280mm 2000mm 1200mm 1920mm 16:10 1394mm 2140mm 87mm 87mm 2264mm 13.8kg
RFST200
£608.95
1530mm 2400mm 1450mm 2320mm 16:10 1644mm 2540mm 87mm 87mm 2736mm 16.7kg
RFST240
£792.87
1910mm 3000mm 1830mm 2920mm 16:10 2042mm 3140mm 105mm 105mm 3446mm 24.8kg
RFST300
£1132.85
1050mm 1800mm 970mm 1720mm 16:9 1164mm 1940mm 87mm 87mm 1975mm 12.3kg
RFW180
£584.27
1160mm 2000mm 1080mm 1920mm 16:9 1274mm 2140mm 87mm 87mm 2203mm 13.7kg
RFW200
£608.95
1390mm 2400mm 1310mm 2320mm 16:9 1504mm 2540mm 87mm 87mm 2664mm 16.6kg
RFW240
£779.54
1720mm 3000mm 1640mm 2920mm 16:9 1852mm 3140mm 105mm 105mm 3349mm 24.7kg
RFW300
£1118.30
Extension Bracket 550mm
RFBKT40
£85.78
Accessories see page 176
Screens include 50mm black borders on all 4 sides.
Additional extended black drop is added at top of screen to create maximum drop length.
* While stocks last
Channel fix mounting
In-ceiling option - see opposite page
B
F
E
C
D
I
A
G
H
Eyeline® Rollfix Key Features
✓
Channel fix mounting
✓
Robust steel construction
✓
High quality white screen fabric
✓
300mm extended backdrop
✓
Remote accessories available
✓
Simple recess installation available
